SIPLUS S7-300 Modules
The following table contains all SIPLUS S7-300 modules.
The order numbers of the corresponding “standard” modules have been included
as an aid to configuration. You can refer to the description and technical
specifications in the special section on the “standard” module.
Table 1-10 SIPLUS S7-300 Modules
Module
SIPLUS S7-300-SIMATIC
module for use under
extended environmental
conditions
”Standard” modules
as of order no.
IM 153-1 6AG1153-1AA03-2XB0 6ES7153-1AA03-0XB0
CPU 312C
CPU 313C
CPU 314
CPU 315-2 DP
6AG1312-5BD00-2AB0
6AG1313-5BE00-2AB0
6AG1314-1AF10-2AB0
6AG1315-2AG10-2AB0
6ES7312-5BD00-0AB0
6ES7313-5BE00-0AB0
6ES7314-1AF10-0AB0
6ES7315-2AG10-0AB0
IM 365 6AG1365-0BA01-2AA0 6ES7365-0BA01-0AA0
SM 321 digital input module;
SM 321; DI 16 x 24VDC
SM 321; DI 32 x 24 VDC
SM 321; DI 16 x 24 VDC
SM 321; DI 16 x 24 V-125 VDC
SM 321; DI 8 x 120/230 VAC
6AG1321-1BH02-2AA0
6AG1321-1BL00-2AA0
6AG1321-7BH01-2AB0
6AG1321-1CH20-2AA0
6AG1321-1FF01-2AA0
6ES7321-1BH02-0AA0
6ES7321-1BL00-0AA0
6ES7321-7BH01-0AB0
6ES7321-1CH20-0AA0
6ES7321-1FF01-0AA0
SM 322 digital output module;
SM 322; DO 16 x 24 VDC/0.5 A
SM 322; DO 8 x Rel. 230 VAC/5 A
SM 322, DO 8 x 48-125 VDC/1.5 A
SM 322; DO 8 x 120/230 VAC/2 A
SM 322; DO 8 x 24 VDC/0.5 A
6AG1322-1BH01-2AA0
6AG1322-1HF10-2AA0
6AG1322-1CF00-2AA0
6AG1322-1FF01-2AA0
6AG1322-8BF00-2AB0
6ES7322-1BH01-0AA0
6ES7322-1HF10-0AA0
6ES7322-1CF00-0AA0
6ES7322-1FF01-0AA0
6ES7322-8BF00-0AB0
Digital Input/Output Module
SM 323; DI8/DO8 x DC 24V/0.5A
6AG1323-1BH01-2AA0 6ES7323-1BH01-0AA0
Analog input module
SM 331 analog input module; AI 2 x 12 bits
6AG1331-7KB02-2AB0 6ES7331-7KB02-0AB0
Analog output module
SM 332 analog output module; AO 2 x 12
bits
6AG1332-5HB01-2AB0 6ES7332-5HB01-0AB0
SM 334 analog I/O module;
SM 334; AI4/AO 2 x 12 bits
6AG1334-0KE00-2AB0 6ES7334-0KE00-0AB0
