394149/C
145
Theillustrationsandexampleshereareprovidedbythefollowingmanufacturer:
RoxtecInternationalAB
Box540
S-37123Karlskrona,SWEDEN
•http://www.roxtec.com
Roxtecsteps(ImagefromRoxtec
website)
TheRoxtecsystemisavailablewithalargenumber
ofvariousmodulesandcompressionunits.Itwill
alsocomplywithscreeningandEMCrequirements.
Procedure
1Cutanopeninginthestructure(bulkhead,
cabinetetc)youwishtopenetrate.
Theholemustbesizedtotoneofthestandard
rectangularorcircularframesprovidedbythe
sealingsystemmanufacturer.
Note
Thechosensolutionmustcomplywiththere
and/orpressuredemandsforthevessel.
Ifthesealingistobeusedunderwater ,both
pressureandmaterialrequirementsmustbe
takenintoconsideration.
2Mounttheframe.
3Pullthecable(s)throughtheframe.
Inmostcasestheopeningwillbelargeenough
toaccepttheplugsonthecables.
4Secureeachcablewithasquaresealingmodule.
5Adjustthemoduletotthecable’souter
diameter.
6Whentherequirednumberofmodules
areinstalled,tightentheassemblywitha
compressionunit.
Furtherrequirements
Formoreinformation,andotherinstallation
procedures,refertothedocumentationprovidedbyRoxtec(oryourmanufacturerofchoice).
Cablelayoutandinterconnections
