Ski-Doo REV Series Shop Manual

Section04ENGINE
Subsection 01 (593, 593 HO, 593 HO SDI AND 793 HO ENGINE TYPES)
A32CC4B
Slide-in the second bearing until it contacts the
first one.
A32CC5B
NOTE: To prevent seal pop-out, it is recom-
mended to use PTO seal
CAUTION: Use only the recommended Isoflex
grease. Make sure not to push Isoflex
grease between outside bearing race and
half crankcase.
NOTE: The 50 g tube corresponds to 50 cc of
grease.
Put50to55mLofgreaseinasyringe.
CAUTION: Do not exceed the recommended
amount of grease
Fill inner side of PTO side bearing with Isoflex
grease (about 10 mL).
A33C15A
PTO SIDE BEARING FILLED WITH ISOFLEX GREASE
With the syringe, fill the outer ball bearing and in-
ner side of outer seal with 40 to 45 mL of Isoflex
grease.
A33C16A
BALLS COATED WITH A SEAM OF GREASE
mmr2004-Rev 107
