242
SVAN 979 User Manual - Appendixes
Word
number
Name
Comment
4
TimeStep
measurement step in milliseconds
5
MeasureTime
measurement time in seconds
6
reserved
7
DispSmooth
parameter "smoothing" of the time curve (0 means no smoothing)
8
NoiseMargin
level of noise margin in the format 0,01 dB
9
reserved
10
AverNo
number of averaged results
…
reserved
Table B.1.23. Alarms events parameters
Word
number
Name
Comment
0
0060h
60h = block identifier
1
BlockLength
block length in words
2
EventCount
number of defined events (Events)
3..10
EventName[1]
name of the first event (16 ASCII symbols)
11
reserved
12
EventType[1]
type of the first event:
0 – block event
1 – point event
...
parameters of the following events
…
reserved
Table B.1.24. STIPA parameters
Word
number
Name
Comment
0
0063h
63h = block identifier
1
BlockLength
block length in words
2
Standard
standard:
0 – IEC 60268-16x2
1 – IEC 60268-16x3
3
Averaging
averaging type:
0 – Manual
1 – Auto
4
N
Project name length
5..
ProjectName[N]
Project name
5+N
M
Area name length
6+N..
AreaName[M]
Area name
6+N+M
PointId
Point Id
7+N+M
K
Source name length
8+N+M..
SourceName[K]
Source name
8+N+M+K
CalibrLevel
Source calibration factor in 0.01 dB format
…
reserved
