Svantek SVAN 979 - Description of Cyclical Results Blocks (Summary Results )

248
SVAN 979 User Manual - Appendixes
Word
number
Name
Comment
4
AlarmEventEmail
bit mask of sent e-mail:
– each bit specifies the sending status of the e-mail for one event (the
lowest bit specifies the e-mail sending status for the first event, the
next one for the second event, and so on)
– set bit indicates that e-mail has been sent
– cleared bit indicates that e-mail has not been sent
– number of available events is defined in the corresponding block of
parameters (see Table B.1.23)
...
reserved
...
0CDnnh
0CDh = block end identifier
0nnh = block length in words
Table B.2.12. Blocks for reserved markers
Word
number
Name
Comment
0
0C7kkh
0C7kkh = block start identifier (0kkh is an additional number from 0
to 127 identifying the block)
1
0nnnnh
block length in words
2..
reserved
...
0nnnnh
block length in words
...
0CFkkh
0CFkkh = block end identifier (0kkh is an additional number from 0 to
127 identifying the block)
B.3. DESCRIPTION OF CYCLICAL RESULTS BLOCKS (SUMMARY RESULTS)
Table B.3.1. Block of counters
Word
number
Name
Comment
0
0nn59h
59h = block identifier
0nnh = block length in words
1..2
CycleNo
measurement cycle number
…
reserved
Table B.3.2. Block of Summary Results
Word
number
Name
Comment
0
0nn07h
07h = block identifier
0nnh = block length in words
1
00pxxh
p = number of profiles, 0xxh = profile bit mask (the bit mask indicates
for which profiles the results are available)
