SVAN 979 User Manual - Appendixes
Table B.2.9. Block of marker for wave file recording
0C2h = block start identifier
0nnh = block length in words
File name (8 ASCII symbols)
0CAh = block end identifier
0nnh = block length in words
Table B.2.10. Block for the Summary Results
0C300h = block start identifier
set of cyclic results blocks; each block has its own header with ID and
block length; blocks of cyclic results are described in chapter B.3.
0CB00h = block end identifier
Table B.2.11. Block of marker for alarms
0C5h = block start identifier
0nnh = block length in words
point event state bit mask:
– each bit specifies the state of one event (the lowest bit defines the
state of the first event, the next one – the second event, and so on),
– set bit indicates that the event is active
– cleared bit indicates that the event is inactive
– number of available events and the type (block or point) are defined
in the corresponding block of parameters (see Table B.1.23)
block event state bit mask:
– each bit specifies the state of one event (the lowest bit defines the
state of the first event, the next one – the second event, and so on)
– set bit indicates that the event is active
– cleared bit indicates that the event is inactive
– number of available events and the type (block or point) are defined
in the corresponding block of parameters (see Table B.1.23)
bit mask of sent SMS:
– each bit specifies the sending status of the SMS for one event (the
lowest bit specifies the SMS sending status for the first event, the
next one for the second event, and so on)
– set bit indicates that SMS has been sent
– cleared bit indicates that SMS has not been sent
– number of available events is defined in the corresponding block of
parameters (see Table B.1.23)
