SVAN 979 User Manual - Appendixes
C.4.2 Digital weighting filters implemented in vibration modes
C.4.2.1 Digital filters implemented in vibration modes for acceleration measurements
“HP1” filter is used for acceleration measurements (vibration signal) in the frequency range 1 Hz - 20 kHz.
“HP1´ filter characteristics
“HP3” filter is used for acceleration measurements (vibration signal) in the frequency range 3.5 Hz - 20 kHz.
”HP3” filter characteristics
“HP10” filter is used for acceleration measurements (vibration signal) in the frequency range 10 Hz - 20 kHz.
“HP10” filter characteristics
