SVAN 979 User Manual - Appendixes
C.3. SPECIFICATION OF SVAN 979 AS 1/1 OCTAVE - 1/12 OCTAVE ANALYSER
SVAN 979 can operate as 1/1-octave, 1/3-octave, 1/6-octave or 1/12-octave analyser conforming to the
international IEC 61260-1:2014 standard for the pass band filters.
Note: Simultaneously to the frequency analysis SVAN 979 operates as Level Meter! See Chapters
C.1 and C.2 for specification.
Signal input
● Connector: 7 pin Lemo.
● Maximum input voltage: the SVAN 979 meets the requirements IEC 348 for the 2
nd
class device. The input
voltage shall not exceed the limits between 0 V and 28 V.
● Impedance: 150 k / 100 pF.
● IEPE transducer or preamplifier powering: 28 V / 1.5 mA or 4.5 mA current source, user-selectable (path:
<Menu> / Instrument / IEPE Current: 1.5 mA as default).
Linear Operating Ranges
Two measurement ranges are available: “LOW” and "HIGH"
Table C.3.1 Linear operating range
Range
Linear operating range (with the error  0.8 dB)
(RMS for the sinusoidal signal at reference conditions @ 1 kHz,
0.0 dB calibration factor)
LOW
from 10 μV
RMS
“A”-weighting
to 1 V
RMS
“A”-weighting
from 10 μV
RMS
“C”-weighting
to 1 V
RMS
“C”-weighting
from 20 μV
RMS
“HP”-weighting
to 1 V
RMS
“HP”-weighting
HIGH
from 30 μV
RMS
“A”-weighting
to 7.07 V
RMS
“A”-weighting
from 30 μV
RMS
“C”-weighting
to 7.07 V
RMS
“C”-weighting
from 50 μV
RMS
“HP”-weighting
to 7.07 V
RMS
“HP”-weighting
Table C.3.2 Peak for the sinusoidal signal 1 kHz, at reference conditions
Peak for the sinusoidal signal 1 kHz, at reference conditions
@ 1 kHz (0.0 dB calibration factor)
Range
Max Peak value
LOW
1.4 V “A”–weighting
1.4 V “C”-weighting
1.4 V “HP”-weighting
HIGH
10 V “A”-weighting
10 V “C”-weighting
10 V “HP”-weighting
