SVAN 979 User Manual - Appendixes
Word
number
Name
Comment
2..
Profile[1]
internal block with identifier 08h with the results for the first profile
whose bitmask is set - see Table B.3.3
...
...
...
...
Profile[p]
internal block with identifier 08h with the results for the last profile
whose bitmask is set - see Table B.3.3
…
reserved
Table B.3.3. Results for one profile (block exists only inside the Summary results block – see Table B.3.2)
Word
number
Name
Comment
0
0nn08h
08h = block identifier
0nnh = block length in words
1..2
Time
for the results of the first profile:
– measurement time in seconds
for the results of the second profile:
– overload duration in seconds
for the results of the third profile:
– duration of excessive vibration in seconds
3
Peak
value of the "Peak" result in the format 0.01 dB
4
P–P/SEL
"P-P" value in 0.01 dB format for vibration measurement mode
or
"SEL" value in 0.01 dB format for sound measurement mode
5
Max
value of the "Max" result in the format 0.01 dB
6
Reserved/ Min
value reserved for vibration measurement mode
or
„Min" value in 0.01 dB format for sound measurement mode
7
Reserved/ Spl
value reserved for vibration measurement mode
or
„Spl" value in 0.01 dB format for sound measurement mode
8
RMS/Leq
"RMS" value in 0.01 dB format for vibration measurement mode
or
"Leq" value in 0.01 dB format for sound measurement mode
9
Reserved/ Lden
value reserved for vibration measurement mode
or
„Lden" value in 0.01 dB format for sound measurement mode
10
Reserved
11
Reserved/ LTeq
value reserved for vibration measurement mode
or
„LTeq" value in 0.01 dB format for sound measurement mode
12
Reserved/ LR1
value reserved for vibration measurement mode
or
„LR1" value in 0.01 dB format for sound measurement mode
13
Reserved/ LR1
value reserved for vibration measurement mode
or
„LR2" value in 0.01 dB format for sound measurement mode
14
reserved
