SVAN 979 User Manual - Appendixes
Word
number
Name
Comment
...
...
...
...
Result[N+T–1]
value of the penultimate result in the format 0,01 dB
...
Result[N+T]
value of the last result in the format 0.01 dB (the number of spectral
bands and the number of total results are specified in the
corresponding octave and partial-octave analysis block of results -
see Table B.1.19Błąd! Nie można odnaleźć źródła odwołania.)
…
reserved
Table B.3.8. Results of FFT analysis
Word
number
Name
Comment
0
00xxh
0xxh = block identifier:
052h – results of averaged spectrum
053h – results of minimum spectrum
054h – results of maximum spectrum
1
BlockLength
block length in words
2
reserved
3..4
NofAver
number of averaged spectra
5
Result[1]
value of the first result in the format 0,01 dB
6
Result[2]
value of the second result in the format 0,01 dB
...
...
...
...
Result[N+T–1]
value of the penultimate result in the format 0,01 dB
...
Result[N+T]
value of the last result in the format 0,01 (number of spectral lines
and the number of aggregate results are determined in the
corresponding FFT analysis block of results - see Table B.1.21)
…
reserved
Table B.3.9. Results of statistical analysis
Word
number
Name
Comment
0
0xx0Bh
0Bh = block identifier
0xxh = profile bit mask
1
BlockLength
block length in words
2..3
Histogram[1]
histogram counter of the first class
4..5
Histogram[2]
histogram counter of the second class
...
...
...
...
Histogram[N–1]
histogram counter of the penultimate class
...
Histogram[N]
histogram counter of the last class (number of statistical classes of
the histogram N is given in the block of profile histogram parameters
- see Table B.1.18)
…
reserved
