FLIGHT PHASES
PREFLIGHT 27
AIRBUS A318/319/320/321
© THALES AVIONICS S.A.
J43126AA 00
 Complete INIT page B
INIT key........................ Press
INIT page A is displayed.
Use horizontal slew keys to
display the INIT B page.
Taxi fuel [1L], RTE RSV % [3L],
FINAL/TIME [5L] are default
values specified by operator in
the AMI data base.
FINAL/TIME is holding at 1500’
(or as specified by operator) at
LW in CONF1.
ZFWCG [1R] defaults to 25.0%.
All these values may be modified
by overwriting.
ZFW [1R]........................Enter
Ex: /58.
When entered these fields
cannot be cleared.
ZFW may also be modified by
overwriting.
BLOCK [2R] ....................Enter
Ex: 7.8.
Title changes to “INIT FUEL
PREDICTION”.
BLOCK fuel may be cleared or
modified by overwriting.
If a F-PLN & CRZ FL have been
entered, the FMGS will now
compute time & fuel predictions,
including turn radius, lateral and
vertical profile.
Trajectory is displayed on ND,
time and fuel predictions are
displayed on F-PLN pages.
Crosscheck fuel & time
predictions against data on
printed CFP.
INIT {}
TAXI ZFWCG/ ZFW
0.2 25.0/ 58.0
TRIP/TIME BLOCK
---.-/---- __._
RTE RSV/%
---.-/ 5.0
ALTN/TIME TOW
---.-/---- ---.-
FINAL/TIME LW
---.-/0030 ---.-
EXTRA/TIME
---.-/----
7.8
INIT {}
CO RTE FROM/TO
TLSLHR01 LFBO/EGLL
ALTN/CO RTE
EHAM/LHRAMS01
FLT NBR
THV001
LAT
$£ LONG
4338.1N 00122.1E
COST INDEX
30 WIND>
CRZ FL/TEMP TROPO
FL360 /-50° 35000
INIT {}
TAXI ZFWCG/ ZFW
0.2 25.0/ __._
TRIP/TIME BLOCK
---.-/---- __._
RTE RSV/%
---.-/ 5.0
ALTN/TIME TOW
---.-/---- ---.-
FINAL/TIME LW
---.-/0030 ---.-
EXTRA/TIME
---.-/----
/58
INIT FUEL PREDICTION {}
TAXI ZFWCG/ ZFW
0.2 25.0/ 58.0
TRIP/TIME BLOCK
3.2/0122 7.8
RTE RSV/%
0.2/ 5.0
ALTN/TIME TOW
1.8/0042 65.6
FINAL/TIME LW
1.0/0030 62.4
EXTRA/TIME
1.4/0038
