MULTIPHASE
VERTICAL F-PLN management 29
CRUISE WIND page
Before any pilot entry, blue brackets
are displayed in [1L].
Ex. 1.
Only one cruise wind can be
entered at a waypoint in the following
format NNN/NNN where NNN is
direction (true referenced) and NNN
magnitude; entered values are
displayed in large blue font.
Ex. 2. Wind 300/40 has been entered
at FOUCO
Once entered, wind data are
propagated at the same altitude to
other cruise WPTs (displayed in blue
small font).
Vertical slew keys are used to scroll
and view cruise waypoints.
Ex. 3. ADABI: propagated wind
entered at FOUCO.
Propagated wind data may be
modified by overwriting (both
direction & magnitude) but not
cleared. Clearing revised data will
revert to the previous propagated
vaues.
Ex. 4. New wind 310/50 is enterec at
DEVRO, overwriting the propagated
wind.
PREV PHASE [4R], NEXT PHASE [5R]
changes display to CLIMB WIND and
DESCENT WIND pages respectively.
UPDATE CANCEL prompt [6L] reverts
display to the page from which wind
data has been accessed.
UPDATE INSERT [6R] performs a
global insertion of all updated winds
data. When this prompt is pressed,
the page reverts to the respective F-
PLN A page oriented with the FROM
waypoint.
CRUISE WIND AT FOUCO
TRU WIND/ALT
[ ]°/[ ] AT FL360
WIND
REQUEST
PREV
PHASE>
NEXT
PHASE>
UPDATE UPDATE
{CANCEL INSERT*
£$
Ex. 1
CRUISE WIND AT FOUCO
TRU WIND/ALT
300°/040 AT FL360
WIND
REQUEST
PREV
PHASE>
NEXT
PHASE>
UPDATE UPDATE
{CANCEL INSERT*
£$
Ex. 2
CRUISE WIND AT ADABI
TRU WIND/ALT
300°/040 AT FL360
WIND
REQUEST
PREV
PHASE>
NEXT
PHASE>
UPDATE UPDATE
{CANCEL INSERT*
£$
Ex. 3
CRUISE WIND AT DEVRO
TRU WIND/ALT
310°/050 AT FL360
WIND
REQUEST
PREV
PHASE>
NEXT
PHASE>
UPDATE UPDATE
{CANCEL INSERT*
£$
. 4
AIRBUS A318/319/320/321
© THALES AVIONICS S.A.
J43126AA 00
