30 VERTICAL F-PLN management
 DESCENT WIND page
Before any pilot entry, blue brackets
are displayed in [1L] (Ex. 1).
Up to 5 DESCENT winds may be
entered in the format NNN/NNN/ALT,
where NNN is direction (TRUE
referenced), NNN magnitude, ALT in
altitude format below TRANS ALT or
FL above (Ex. 2 shows a sample).
Modifications of existing data may be
made by:
Ex. 1
DESCENT WIND
TRU WIND/ALT ALTN WIND
[ ]°/[ ]/[ ] [ ]°/[ ]
FL310
WIND
REQUEST
PREV
PHASE>
UPDATE UPDATE
{CANCEL INSERT*
− Using CLR function on appropriate
left LSK, or
Ex. 2
DESCENT WIND
TRU WIND/ALT ALTN WIND
320°/040/FL300 300°/035
FL310
300°/030/FL200
WIND
290°/020/FL100 REQUEST
PREV
247°/015/GRND PHASE>
[ ]°/[ ]/[ ]
UPDATE UPDATE
{CANCEL INSERT*
− Overwriting existing data with the
following formats: NNN/NNN/ALT,
or NNN/NNN for wind only, or /ALT
for altitude only.
Pilot-inserted data are written large
blue font.
DESCENT winds are sorted in
descending altitude order. After each
modification of an altitude, the list is
resorted.
A GND wind inserted in APP page
automatically insert or update the
DESCENT WIND page (direction is
converted to true). (Ex. 3).
When FMGC has switched to DES
phase, wind data are green and no
longer modifiable (Ex. 4).
PREV PHASE [5R] prompt enables to
change display to CRUISE WIND
page; it is no longer available when
FMGC has switched to DES phase.
UPDATE CANCEL prompt [6L] reverts
display to the page from which wind
data has been accessed.
UPDATE INSERT [6R] performs a
global insertion of all updated winds
data. When this prompt is pressed,
the page reverts to the respective F-
PLN A page oriented with the FROM
waypoint.
Descent winds (including alternate
wind) are automatically deleted if the
destination airport is changed.
DEST APPR
QNH FLP RETR FINAL
1015 F=168 ILS27R
TEMP SLT RETR MDA
15° S=186 278
MAG WIND CLEAN DH
250°/15 O=225 [ ]
TRANS ALT LOG CONF
6000 CONF3*
VAPP VLS
137 132 FULL
PREV NEXT
<PHASE PHASE>
Ex. 3
Ex. 4
DESCENT WIND
TRU WIND/ALT ALTN WIND
320°/040/FL300 300°/035
FL310
300°/030/FL200
WIND
290°/020/FL100 REQUEST
247°/015/GRND
<RETURN
