VERTICAL F-PLN management 35
 To delete a STEP CLB or
DES
From VERT REV At any WPT
STEP ALTS [5R].......Press
CLR [1L] ................. Enter
TMPY STEPS ALT is
displayed.
TMPY F-PLN [6L].....Press
TMPY F-PLN page is
displayed.
TMPY INSERT [6R] ..Press
STEP CLB or DES may also
be deleted directly on F-PLN
page A by using CLR
function left or right LSK
adjacent to S/C or S/D.
This method is not
recommended since it
could result in inadvertent
deletion of a WPT, if a
simultaneous leg-switching
occurs.
FROM TMPY THV001 {}
UTC SPD/ALT
T-P 0115 / FL360
BRG315° 114
ABUDA 0132 .79/ FL360
TRK330° 10
(S/C) 0017 279/ FL280
UN874 30
BOKNO 0022 " / FL354
3NM
(T/C) 0022 .77/ FL360
TMPY TMPY
{ERASE INSERT*
$£
FROM THV001 {}
UTC SPD/ALT
T-P 0115 / FL360
BRG357° 43
ABUDA 0130 .79/ FL360
TRK330° 0
BOKNO 0018 " / FL360
UN874 27
DEVRO 0022 " / FL298
UN874 22NM
VANAD 0025 " / FL343
DEST UTC DIST EFOB
EGLL27R 0107 383 3.9
£$
STEP ALTS FROM FL360
ALT / WPT DIST UTC
[ ] /[ ]
TMPY
<F-PLN
VERT REV AT ABUDA
EFOB=4.3 EXTRA=1.1
CLB SPD LIM
250/FL100
SPD CSTR ALT CSTR
[ ] [ ]
ACCESS
<WIND DATA STEP ALTS>
<RETURN
STEP ALTS FROM FL360
ALT / WPT DIST UTC
FL280/ABUDA 98 0131
<RETURN
CLR
FROM THV001 {}
UTC SPD/ALT
T-P 0115 / FL360
BRG015° 98
ABUDA 0132 .79/ FL360
TRK330° 10
(T/D) 0133 .79/ FL360
UT426 17
DIMAL 0136 " / FL308
7NM
ALESO 0137 293 / FL286
DEST UTC DIST EFOB
EGLL27R 0156 218 3.9
£$
