APPENDICES
MCDU NAMING and DATA FORMAT 25
DATA NAME FORMAT
RANGE
(X is input)
UNITS
MCDU PAGE
PLACE/DIST PLACE: same as for
PLACE/BRG/DIST
DIST: same as for
PLACE/BRG/DIST
PLACE:
same as for
PLACE/BRG/DIST
DIST:
-999.9 to +999.9
N/A
NM
F-PLN A/B
SEC
F-PLN A/B
WAYPOINT
PILOT WPT
STEP ALTS
QFE NNNN
Leading or trailing
zeros may be omitted
NN.NN
Leading or trailing
zeros may be omitted
745.0 – 1050.0
(Hpa)
22.00 – 31.01
(In Hg)
Hecto-
Pascals
In Hg
UPLINK TO
DATA
QNH NNNN
Leading or trailing
zeros may be omitted
NN.NN
Leading or trailing
zeros may be omitted
745.0 – 1050.0
(Hpa)
22.00 – 31.01
(In Hg)
Hecto-
Pascals
In Hg
APPROACH
RADIAL IN NNN
Leading zeros may be
omitted. An entry of
360 is displayed as 0.
000 – 360
Degrees
DIR TO
RADIAL OUT NNN
Leading zeros may be
omitted. An entry of
360 is displayed as 0.
000 – 360
Degrees
DIR TO,
REQUIRED
ACCUR
NN.NN
Leading or trailing
zero may be omitted
0.01 – 20.0
NM
PROGRESS
UTC CSTR HHMMSS or HHMM 0 – 23
0 – 59
0 – 59
H
MN
S
VERT REV
RTE RSV
RTE RSV%
Only one may be
entered at a time.
To input
RTE RSV
enter NN.N
To input
RTE RSV %
enter /NN.N
0 – Max RTE RSV
RTE RSV% =
0 – 15 %
Thousands
of Kg or lb.
(OPC
option)
%
INIT B
FUEL PRED
RWY AAAANND
AAAA is same as
ARPT
NN is runway number
(2 digits must be
entered)
D is L or R or C (Left
/ Right / Center)
RUNWAY,
NEW RUNWAY
NEW NAVAID
