APPENDICES
26 MCDU NAMING and DATA FORMAT
DATA NAME FORMAT
RANGE
(X is input)
UNITS
MCDU PAGE
RWY
INTERSECTION
NNDAAA
NN is runway number
(2 digits must be
entered),
D is L or R or C,
depending on the
runway AAA are
3 alphanumeric
characters
UPLINK TAKE
OFF DATA
SAT/ALT TEMP/ALT See TEMP and ALT
N/A
CRUISE WIND
SATELLITE
NUMBER
NN
Leading zero may be
omitted
1 – 99
N/A
PREDICTIVE
GPS
SET HDG NNN.N
Leading and trailing
zeros may be omitted
Will always be
displayed as NNN.N
000.0 – 359.9
Degrees
IRS MONITOR
SHIFT/RWY
(2)
NNNNN/NND NNNNN same as
TO SHIFT
NND same as RWY
Same as
to SHIFT
UPLINK TO
DATA REQ
SLOPE N.N 0.0 – 9.9
Degrees
NEW NAVAID
SPD NNN
Must be 3 numeric
characters
MAX = VMO
MIN = 100 KT
KT (CAS)
F-PLN A
SEC F-PLN A
VERT REV
PERF CLB
PERF CRZ
PERF DES
SPD LIM SSS/NNNNN
SSS is a speed
NNNNN is an ALT or
FLIGHT LEVEL (see
ALT and FLIGHT
LEVEL)
SSS same as SPD
KT/ft
(MSL)
or
KT/FL
VERT REV
F-PLN A
SPD/MACH See MACH/SPD Same as MACH
and SPD
Same as
MACH and
SPD
PERF DES
STATION DEC NNND
NNN is the
declination (magnetic
variation) is the
direction. Leading
zeros may be
omitted.
D is not required for
an entry of zero
declination
NNN: 00 – 180
D: E or W
Degrees
NEW NAVAID
STEP ALT SNNN or NNNS
NNN is in Flight
Level, or
SNNNNN or NNNNNS
NNNNN is in ALT
Leading zeros may be
omitted
Same as Flight
Level or ALT
Same as
Flight
Level or
ALT
F-PLN A
J43126AA 00
© THALES AVIONICS S.A.
AIRBUS A318/319/320/321
