APPENDICES
MCDU NAMING and DATA FORMAT 27
DATA NAME FORMAT
RANGE
(X is input)
UNITS
MCDU PAGE
TO LIMIT
(2)
NNNNN 1 – Length of
origin runway
M or ft
(OPC
option)
UPLINK TO
DATA REQ
T.O. SHIFT NNNNN 1 – Length of
origin runway
M or ft
(OPC
option)
TAKE OFF
TAXI N.N
Leading or trailing
zeros may be omitted
0 – 9.9
Thousands
of Kg or lb.
(OPC
option)
INIT B
TEMP
± NN
If no sign, assume +
Degrees
centigrade
APPROACH,
TAKE OFF
THR RED ALT Same as ALT
ft (MSL)
TAKE OFF
GO AROUND
THS AAN.N or N.NAA
AA is UP or DN
(DOWN)
Trailing zeros may be
omitted
Max UP = 7.0
Max DN = 5.0
Min UP and DN is
0.0 the increment
value is .1
Degrees
TAKE OFF
TIME N.N 0 - 9.9
Minutes
HOLD
TRANS ALT Same as ALT
ft (MSL)
TAKE OFF
APPROACH
TRIP WIND See EFF WIND
KT
INIT B
SEC INIT B
TROPO An entry of NNNN or
NNNNN is
considered as an
ALTITUDE
An entry of NNN or
NN is considered as
a FLIGHT LEVEL
ALT: 1000 –
99990 (Altitude
entry is rounded
to the nearest 10
feet)
FL: 10 – 999
Same as
ALT or
FLIGHT
LEVEL
FUEL PRED
INIT A
SEC INIT A
UPDATE AT Same as WAYPOINT Same as
WAYPOINT
N/A
PROG
V1 Same as SPD
KT (CAS)
TAKE OFF
V2 Same as SPD
KT (CAS)
TAKE OFF
VAPP Same as SPD
KT (CAS)
APPROACH
VR Same as SPD
KT (CAS)
TAKE OFF
WAYPOINT XXXXXXX
May be from 1 – 7
characters.
Acceptable as
waypoint Ident,
ARPT, NAVAID,
WAYPOINT,
LAT/LONG,
PLACE.BRG/
PLACE.BRG
PLACE/BRG/DIST
PLACE/DIST may be
entered to define a
waypoint
WAYPOINT
NEW WAYPOINT
F.PLN A/B
LAT REV
PROG,
DIR TO
STEP ALTS
PREDICTIVE
GPS
VERT REV
SEC INIT A
