33
CAPTURING TOMOGRAMS
How to use the menu
[Fovea Pos.]
"Fovea pos" is valid for the "3D Macula (V)" and "3D Wide" photography.
The layer thickness (Retina/RNFL/GCL+/GCL++) in each Grid is calculated with the Grid center at the
Fovea position. The default Fovea position is automatically detected during analysis and is the posi-
tion estimated from the retinal thickness.
Function Navigation ON Navigation OFF
Fovea Pos. [Fovea Pos.] [On]:
Changes to "On" for fovea
position display.
When "On" is set, the
Fovea position is displayed.
[Fovea Pos.] [Off]:
Changes to "Off" for fovea position
display.
Fovea pos. position display mode
