Toro Groundmaster Series - Adjusting the Traction System for Neutral

Adjustments
AdjustingtheTractionSystemforNeutral
ThetractionpedalmustreturntotheNEUTRALpositionwhenreleasedfromeither
theforwardorreverseposition.Themachinemustnotcreepineitherdirection
onlevelgroundwheninthetractionpedalisintheNEUTRALposition.Adjustthe
tractionsystemforneutralasfollows:
1.Parkthemachineonalevelsurface,lowerthecuttingunit(orattachment)
andsetthekeyswitchtotheOFFposition.
WARNING
ReviewandfollowtheJackingInstructions(page1–6)beforelifting
themachine.
2.Raisebothfrontwheelsfor2WDmachines,orall4wheelsfor4WDmachines
offtheoorandsupportthemachine.
3.Loosenthelocknutonthetraction(piston)pumpadjustmentcam.
g301757
Figure43
1.Traction(piston)pump
3.Adjustmentcam
2.Locknut
4.Starttheengineandrotatethecamineitherdirectionuntilthewheelsstop
rotating.
