Doors
g316367
Figure150
(rightsidedoorshown)
1.Doorhandleassembly7.Latchassembly
2.Doorpanelw/seal
8.Latchsupportplate
3.Neopreneangebushing(18each)9.Washer(5each)
4.Hinge(2each)10.Shoulderscrew(9each)
5.Doorframe11.Gasket
6.Locknut
CAUTION
Eachdoorassemblyweighsapproximately424kg(52lbs).
Ensurethedoorgasstrutisproperlyinstalled(rodendtocabframe,cylinder
endtodoorframe).
