Toro Groundmaster Series - Steering Control Valve Service

SteeringControlValveService
g303292
Figure65
1.Reliefvalveassembly9.Crosspin
17.Endcover
2.Dustsealring
10.Sleeve18.Tube(2each)
3.Steeringvalvehousing11.Spool19.Washer(5each)
4.Shaftseal12.Cardanshaft
20.Pinbolt
5.Thrustwasher
13.O-ring21.Capscrew(4each)
6.Bearingrace14.Distributorplate22.Ball
7.Ring
15.Outergearwheel
8.Springset
16.Innergearwheel
Forthesteeringcontrolvalverepairprocedures;refertotheDanfossSteering
UnitTypeOSPMServiceManual.
Groundsmaster
®
3200,3300and3310
Page5–97
HydraulicSystem:ServiceandRepairs
19240SLRevA
