Toro Groundmaster Series - Windshield Washer;Wiper Switch (Model 31903 and 31909)

WindshieldWasher/WiperSwitch(Model31903and31909)
POSITIONCLOSED
CIRCUITS
OFF
1+2
WIPER2+3
WASHER
2+3,5+6
Thewindshieldwasher/wiperswitchislocatedinthecabcontrolpanelcover.
Thewindshieldwasher/wiperswitchcontrolstheoperationofthewindshield
wiperandthewasherpump.Thewindshieldwasher/wiperswitchreceivespower
fromfuseF−3(20Amp)inthecabfuseblock.
TestingtheWindshieldWasher/WiperSwitch
1.Parkthemachineonalevelsurface,lowerthecuttingunit(orattachment),
engagetheparkingbrake,setthekeyswitchtotheOFFpositionandremove
thekeyfromthekeyswitch.
2.Removetheswitchplatefromthecontrolpanelcover.
3.Disconnectthewireharnesselectricalconnectorfromthewindshield
wiper/washerswitch.Checktheswitchandtheharnessconnectorfor
damageorcorrosionandcleanorrepairifnecessary.
4.Useamultimeter(ohmssetting)andtheprecedingtabletodetermine
whethercontinuityexistsbetweenthevariousterminalsforeachswitch
position.
5.Replacethewindshieldwiper/washerswitchifnecessary.
6.Ifthewindshieldwiper/washerswitchtestingiscorrectandacircuitproblem
stillexists,checkthewireharness;refertoAppendixA(pageA–1).
7.Connectthewireharnesstothewindshieldwiper/washerswitch.
8.Installtheswitchplate.
Groundsmaster
®
3200,3300and3310
Page6–37
ElectricalSystem:TestingtheElectricalComponents
19240SLRevA
