FuelPump
g304147
Figure100
1.Fuelpump
2.Fuelhose(disconnected)3.Fuellter
FuelPumpSpecications
PumpCapacity700ml(23.5uidounces)perminute
Pressure
22.8kPa(3.3psi)
CurrentDraw
0.9amp
TestingtheFuelPump
ThefuelpumpusedontheGroundsmaster3200/3300/3310machinesis
attachedtothesupportbracketatthefrontoftheengine.Testingthefuelpump
involvesmeasuringtheamountoffuelanunrestrictedpumpcandeliverovera
setperiodoftime.
RefertoFigure100forthisprocedure.
1.Parkthemachineonalevelsurface,lowerthecuttingunit(orattachment),
engagetheparkingbrake,setthekeyswitchtotheOFFpositionandremove
thekeyfromthekeyswitch.
2.Ensurethatthefuelhosesattachedtothefuelpumparefreeofobstructions.
3.Drainthefuel/waterseparator;refertothetractionunitOperator’sManual.
Verifyseparatorelementageandconditionandreplaceifnecessary.
Note:Sincethefuel/waterseparatorisupstreamofthefuelpump,the
conditionofthefuel/waterseparatorwillinuencefuelpumpperformance.
4.Disconnectthefuelhosecomingfromthefuelpumpatthefuellter.Check
theharnessconnectorsfordamageorcorrosionandcleanorrepairif
necessary.
