Toro Groundmaster Series - Traction Pump Drive

TractionPumpDrive
ReplacingtheTractionPumpDriveBelt
g316420
Figure49
1.Idlerarm3.Pumppulley
2.Drivebelt
1.Parkthemachineonalevelsurface,lowerthecuttingunit(orattachment),
engagetheparkingbrake,setthekeyswitchtotheOFFpositionandremove
thekeyfromthekeyswitch.
2.Raisethehood.
3.Usea1/2inchsquaredriveonthehydraulicpumpdrivebeltidlerarmto
relievethebelttensionandremovethebeltfromtheidlerandpumppulleys.
4.DisconnectthecuttingunitdriveshaftatthePTOclutch.
5.RemovetheclutchstopstrapfromthePTOclutch.
6.GuidethebeltoverthePTOclutchandoutofthemachine.
7.Toinstallthenewdrivebelt,followthisprocedureinreverseorder.
Groundsmaster
®
3200,3300and3310
Page5–67
HydraulicSystem:ServiceandRepairs
19240SLRevA
