Toro Groundmaster Series - Mechanical Suspension Seat (Model 31981)

MechanicalSuspensionSeat(Model31981)
g314958
Figure127
1.Upperconsolemountkit
7.Seatbeltkit
2.Bracketkit
8.Seattrackkit
3.Lowerconsolemount
9.Seatswitch
4.Backcover10.Weightadjustknob
5.Cushioncover
11.Bellows
6.Seatswitchharness
12.Armrestkit
Chassis:ServiceandRepairs
Page7–28
Groundsmaster
®
3200,3300and3310
19240SLRevA
