Toro Groundmaster Series - Steering Cylinder Service

SteeringCylinderService
g303568
Figure69
1.Barrel7.Rodseal13.Externalretainingring
2.Locknut8.Rodwearring14.Rod
3.Pistonwearring9.Rodwiper15.Wipersealmask
4.Rodseal10.Dualseal16.Repairkit
5.Pistonseal11.Internalretainingring
6.Piston
12.Cylinderhead
Ifitemsotherthanthecylindersealsarewornordamaged,thecylindermust
bereplacedasacompleteassembly.Disassemble,inspect,andassemblethe
cylinderforinspectionandsealreplacementonly.
Thecylinderrepairkitincludesspecialtoolsrequiredtoreplacethecylinder
seals.Refertothedetailedinstructionsincludedwiththerepairkit,and
viewtheinstructionalvideoHowtoRepairaWireRingCylinderfoundat
http://www.monarchindustries.com/lion-hydraulics/media
priortoservicingthe
cylinder.
Groundsmaster
®
3200,3300and3310
Page5–101
HydraulicSystem:ServiceandRepairs
19240SLRevA
