Toro Groundmaster Series - Multifunction Switch (Optional)

MultifunctionSwitch(Optional)
POSITIONCLOSED
CIRCUITS
ALLOFFNONE
HORN
4+8
ROAD
LIGHTS
1+9
WORK
LIGHTS
3+9
ROADand
WORK
LIGHTS
1+3+9
TURN
SIGNALS
(Turn
Right)
2+6
TURN
SIGNALS
(TurnLeft)
2+7
Themultifunctionswitchisusedtocontroltheoptionalworklights,roadlights,
turnsignals,andhorn.Theswitchislocatedintheoptionalsteeringcolumn
controlpod.
TestingtheMultifunctionSwitch
1.Parkthemachineonalevelsurface,lowerthecuttingunit(orattachment),
engagetheparkingbrake,setthekeyswitchtotheOFFpositionandremove
thekeyfromthekeyswitch.
2.Disconnectthebatterynegative(-)cableatthebattery;refertoRemoving
andInstallingtheBattery(page6–64).
3.Toaccesstheswitch,removethecoverfromthesteeringcolumncontrolpod.
4.Disconnectthemachinewireharnessconnectorfromthemultifunction
switch.Checktheswitchandtheharnessconnectorfordamageorcorrosion
andcleanorrepairifnecessary.
5.Useamultimeter(ohmssetting)andtheprecedingtabletodetermine
whethercontinuityexistsbetweenthevariousterminalsforeachswitch
position.
6.Replacetheswitchiftestingdeterminesthattheswitchisdamaged.
7.Iftheswitchtestingiscorrectandacircuitproblemstillexists,checkthewire
harnesses;refertoAppendixA(pageA–1).
8.Afteryoucompletethetesting,connectthemachinewireharnessconnector
totheswitchandinstallthecontrolpodcover.
