Toro Groundmaster Series - Traction Neutral Switch

TractionNeutralSwitch
g304274
Figure88
1.Capscrew(2each)
8.Pumplever
2.Neutralswitch9.Pinchbolt
3.Jamnut(2each)10.Capscrew(2each)
4.Lockwasher(2each)11.Capscrew
5.Locknut12.Balljoint
6.Supportbracket13.Spacer–5mm(0.21inch)
7.Damper14.Tractioncable
Thetractionneutralswitchisanormallyopenproximityswitchthatcloseswhen
thetractionpedalisintheneutralposition.Theswitchmountstoabracketon
thetraction(piston)pump.Thesensingelementforthetractionneutralswitch
isthetractionpumpleverthatissecuredtothepumpcontrolarm.Whenthe
tractioncontrollinkageisintheNEUTRALposition,thepumpleverwillbenear
theswitchfaceandtheswitchwillbeclosed.Whenthetractionlinkagemoves
towardForwardorReverse,thepumplevermovesawayfromtheswitchface
andtheswitchopens.
WiththekeyswitchintheRUNposition,theLEDonthecableendoftheneutral
switchshouldbeilluminatedwhenthetractionsystemisintheNEUTRALposition.
UseasmallmirrortoviewtheLEDifnecessary.
TheTDMdisplay/controllermonitorsthepositionofthetractionneutralswitch.
Thetractionneutralswitchispartofthemachinesafetyinterlocksystem.Using
thetractionneutralswitchposition(openorclosed)andavarietyofotherinputs,
theTDMdisplay/controllermanagesavarietyofmachinefunctions.
AdjustingtheTractionNeutralSwitch
1.Checkandadjusttractionsystemneutralposition;refertoAdjustingthe
TractionSystemforNeutral(page5–50).
Groundsmaster
®
3200,3300and3310
Page6–29
ElectricalSystem:TestingtheElectricalComponents
19240SLRevA
