Toro Groundmaster Series - Service and Repairs; Rotary Cutting Units

ServiceandRepairs
WARNING
DonotstarttheengineandengagethePTOswitchwhenthePTO
shaftisdisconnectedfromthecuttingunit.Ifyoustarttheengine
andthePTOshaftisallowedtorotate,seriouspersonalinjuryand
machinedamagecouldresult.
IfthePTOshaftisdisconnectedfromthecuttingunit,disconnect
thePTOelectricclutchelectricalconnector.
CAUTION
Donotworkonthecuttingunitorliftarmswiththeenginerunning.
Alwaysshutofftheengineandremovethekeyfromthekeyswitch
beforeworkingonthecuttingunit.
RotaryCuttingUnits
RefertospeciccuttingunitOperator’sManualforthecuttingunitremovaland
installationprocedures.
Tightenthecuttingunitbumperpadmountingscrewsuntilthescrewheadsare
justbelowthesurfaceofthepad;refertoFigure131).
g315013
Figure131
CuttingUnitBumperPad(typical)
Groundsmaster
®
3200,3300and3310
Page8–3
CuttingUnits:ServiceandRepairs
19240SLRevA
