Toro Groundmaster Series - Service and Repairs; Wheels

ServiceandRepairs
Wheels
g302853
Figure111
1.Frontwheelandtire–allmodels4.Rearwheelandtire–2WDmodels
7.Cap
2.Lugnut(asrequired)
5.Flatwasher
8.Capscrew
3.Rearwheelandtire–4WDmodels6.Washer
RemovingandInstallingtheWheels
1.Parkthemachineonalevelsurface,lowerthecuttingunit(orattachment),
setthekeyswitchtotheOFFpositionandremovethekeyfromthekeyswitch.
2.Loosen,butdonotremovethefasteners(lugnutsorcapscrews)thatsecure
thewheelbeingremovedtothemachine.
IMPORTANT
Beforeliftingthemachinewithajack,reviewandfollowJacking
Instructions(page1–6).
3.Raisethemachineuntilthewheeltoberemovedisofftheground.Support
themachinewithappropriatejackstands.
4.Removethefastenersthatsecurethewheelbeingremovedtothemachine,
andremovethewheel.
5.Fitthewheeltothemachineandinstallthefasteners(lugnutsorcapscrews)
snugly.
6.Removethejackstandsandlowerthemachinetotheground.
Groundsmaster
®
3200,3300and3310
Page7–5
Chassis:ServiceandRepairs
19240SLRevA
