Toro Groundmaster Series - Jacking Instructions

JackingInstructions
DANGER
Mechanicalorhydraulicjacksmayfailtosupportthemachineand
causeaseriousinjury.
•Usejackstandstosupporttheraisedmachine.
•Useonlymechanicalorhydraulicjackstoliftthemachine.
•Donotusethecuttingunitorimplementasajackingpoint.
1.Parkthemachineonalevelsurface,lowerthecuttingunit(orattachment),
engagetheparkingbrake,setthekeyswitchtotheOFFpositionandremove
thekeyfromthekeyswitch.
2.engagetheparkingbrakeandblockthe2rearwheelswithchockstoprevent
themachinefrommoving.
3.Positionthejacksecurelyunderthedesiredjackpoint:
•Front=Positionthejacksecurelyundertheframetubejustbehindthe
frontwheel.
•Rear=Positionthejacksecurelyundertheframedirectlyinfrontofthe
rearaxle.
Afterraisingthemachine,useanappropriatejackstandunderthemachine
frametosupportthemachine.
g303670
Figure1
1.Jackpoint–front
3.Jackpoint–rear
2.Jackstandpoint–front
4.Jackstandpoint–rear
IMPORTANT
Usetwojackstandswhensupportingthemachine.
Safety:JackingInstructions
Page1–6
Groundsmaster
®
3200,3300and3310
19240SLRevA
