Toro Groundmaster Series - Servicing the Battery

ServicingtheBattery
g307125
Figure107
1.Battery
7.Starterconnection
2.Batterycover8.Alternatorcable
3.Batteryclamp9.Fusiblelinkharness
4.Negative(-)cable
10.Enginegroundconnection
5.Boot
11.Capscrew
6.Positive(+)cable12.Chassisgroundconnection
BatterySpecications
Battery-electrolytespecicgravityFullyCharged:1.25to1.28at27°C(80°F)
Discharged:lessthan1.24
BatteryspecicationsBCIGroup26
540CCAat-18°C(0°F)
ReserveCapacityof80minutesat27°C(80°F)
Batterydimensions(includingterminalposts
andcaps)
Length22.4cm(8.8inches)
Width13.2cm(6.6inches)
Height18.3cm(8.0inches)
Thebatteryistheheartoftheelectricalsystem.Withtheregularandcorrect
service,thebatterylifecanbeextended.Additionally,thebatteryandelectrical
componentfailurecanbeprevented.
