TestingtheCANbus(continued)
LocationHarness
Connector
Pin
Wire
Color
Expected
Reading
ConnectorGraphic
1MainP37A
Red/White
2MainP37B
Black/White
54to66
ohms
Note:Areadingof120ohmsindicatesoneoftheCANbusterminator
resistorsisnotconnectedordamaged
RefertoCANbusT erminatorResistors(page6–56)and/orAppendixA
(pageA–1)foradditionalinformation.Ifnecessary,contactanAuthorized
ToroDistributorforassistance.
3.Installtheconnectorcoveraftertesting.
