MachineFaults(continued)
MachineFaults(continued)
Fault
ID
FaultTitle
Fault
Condition/Circuit
Description
AdditionalNotes
ServiceActions
P06E9
StarterTimeoutStarterhas
beenengaged
continuouslyfor
morethan30
seconds.
Starterisdisabled.1.Verifythekeyswitchisnotstuckinthe
startposition.
2.Checkthewireharnessconnector(P26)
fordamageorcorrosionandcleanor
repairifnecessary.
3.Testkeyswitchandreplaceifnecessary.
P100CEngineCoolant
TemperatureAbove
Threshold-PTO
Disabled
Enginecoolant
temperaturehas
exceeded105°C
(221°F)
PTOisdisabled.
1.Allowtheenginetocool.
2.Checkthefanconditionandoperation.
3.Cleartheairowscreensandpassages.
4.Checkthecoolantlevelandcondition,
adjustandreplacethecoolantif
necessary.
5.Checkthetemperaturesenderwiringand
connector.
•Model31900/01(P100,J05)
•Model31902/03(P01,P240,Yanmar
enginewireharnessatthetemperature
sender).
6.Testtemperaturesenderandreplaceif
necessary.
P100D
EngineCoolant
TemperatureAbove
Threshold-Engine
ShutDown
Enginecoolant
temperaturehas
exceeded115°C
(239°F)
Engineisshutdown.1.Allowtheenginetocool.
2.Checkthefanconditionandoperation.
3.Cleartheairowscreensandpassages.
4.Checkthecoolantlevelandcondition,
adjustandreplacethecoolantif
necessary.
5.Checkthetemperaturesenderwiringand
connector.
•Model31900/01(J05)
•Model31902/03(P01,P240,Yanmar
enginewireharnessatthetemperature
sender).
6.Testtemperaturesenderandreplaceif
necessary.
P2530
KeyStart/Run
CorrelationFault
Keystartinput
isactivebutthe
keyruninputis
inactive.
Machinewillshut
downsincekeyrun
inputisinactive.
1.TestfuseF3infuseblock1(10A)and
replaceifnecessary.
2.Checkthewireharnessconnector(P26,
P100)fordamageorcorrosionandclean
orrepairifnecessary.
3.Testthecircuitwiringbetweenfuse
F3infuseblock1(10A)andtheTDM
controller.
4.Testthekeyswitchandreplaceif
necessary.
Groundsmaster
®
3200,3300and3310
Page3–9
Troubleshooting:CuttingUnit(orattachment)Problems
19240SLRevA
