8-4 Phaser 7750 Printer Service Manual
Covers
Right Side Cover
1. Open the front cover.
2. Remove 3 screws; 1 screw is located behind the right-hand door.
3. Lightly press downward to release the four hidden tabs behind the right side
cover, then pull the cover away from the printer.
S7700-033
Right-Hand Door
Tabs (4x)
Finisher
J800
