Xerox 7750DXF - Phaser Color Laser Printer - Image Processor Board and Rear Panel Host Interface

General Information 1-7
Image Processor Board and Rear Panel Host
Interface
The components on the image processor board are illustrated in the following figure.
1. RAM (SODIMM) 6. Processor Fan
2. RAM (SODIMM) 7. NVRAM
3. USB Connector 8. Ethernet Connector
4. Health LEDs
5. Hard Drive
7750-170
7
4
8
3
6
2
1
5
