11-46 Phaser 7750 Printer Service Manual
PL 17.4 Horizontal Transport Assembly: 2 of 2
Horizontal Transport Assembly: 2 of 2 PL 17.4
No. Part Number Qty Description
1
H-Transport Roll (in)
2
H-Transport Roll (out)
3
116-1284-00 1 H-Transport Belt
4
Roll
5
Support
6
1 Bearing
7
Harness Guide
8
Cover
9
116-1644-00 Entrance Sensor
s7750-407
