Xerox 7750DXF - Phaser Color Laser Printer - Part List 2.8 Left Cover Assembly: 1 of 2

Service Parts Lists 9-13
Part List 2.8 Left Cover Assembly: 1 of 2
Left Cover Assembly: 1 of 2 PL 2.8
No Part number Qty Part Description and (part name)
3
108R00579 2nd BTR/Transfer Roller Assembly (2NDBTR
ASSEMBLY)
12
116-1543-00 Exit Switch Assembly (SWITCH ASSY-EXIT
14
116-1098-00 Duplex Chute Assembly (CHUTE ASSY-DUP)
16
116-1182-00 Left Cover Assembly
17
116-1759-00 Exit Roller Assembly
s7750-355
