10-2 Phaser 7750 Printer Service Manual
Plug/Jack Locations
Plug/
Jack No. Map Number Item No.
Title
2 Map 12 8 HVPS T1, T3, +24V LVPS
15A Map 16 19 I/F PWB, MAIN Motor, LVPS T2
16 Map 16 16 I/F PWB, MAIN Motor, LVPS T2
42 Map 18 10 AC Drive PWB, Noise Filter PWB, Delay PWB
43 Map 18 11 AC Drive PWB, Noise Filter PWB, Delay PWB
46 Map 18 1 AC Drive PWB, Noise Filter PWB, Delay PWB
J70 Map 18 12 AC Drive PWB, Noise Filter PWB, Delay PWB
72 Map 12 9 HVPS T1, T2, +24V LVPS
102 Map 3 1 Inverter Transport Assembly
103 Map 8 4 MSI Unit
104 Map 7 3 Exit Transport Assembly
106 Map 19 3 Left Lower Assembly, Tray 2 Feeder
108 Map 19 2 Left Lower Assembly, Tray 2 Feeder
109 Map 5 4 Registration Transport Assembly
111 Map 3 14 Inverter Transport Assembly
113 Map 3 8 Inverter Transport Assembly
115 Map 17 10 Developer Motor, Tray 2 Size Switch
116 Map 2 3 MOB Sensor Assembly
117 Map 2 1 MOB Sensor Assembly
119 Map 11 5 IBT Belt Assembly
121 Map 11 4 IBT Belt Assembly
122 Map 11 2 IBT Belt Assembly
125 Map 19 7 Left Lower Assembly, Tray 2 Feeder
129 Map 1 10 Xerographic
130 Map 1 9 Xerographic
131 Map 1 7 Xerographic
132 Map 1 5 Xerographic
133 Map 1 16 Xerographic
135 Map 4 5 Duplex Transport Assembly
136 Map 4 6 Duplex Transport Assembly
