11-7
Horizontal Transport Sensor, Interlock and Switch
Locations
IOT Face Down
Tray Full Sensor
H-Transport
Entrance Sensor
Gate In Solenoid
H-Transport Interlock Sensor
H-Transport Exit Sensor
S7700-447
