3-12 Phaser 7750 Printer Service Manual
Error Messages and Codes Procedures
Laser Unit Failure, Code 10
Laser Unit Polygon Motor Failure, Code 11
Note
If this failure reoccurs three times successively, an Engine NVRAM value is set
preventing further printer use until the Clear Tech Rep Fault (see pg. 6-20) is
performed.
Applicable Parts Wiring and Plug/Jack Map Diagrams
■ Laser Assembly ■
■
Engine Control Board ■
Troubleshooting Procedure
Step Actions and Questions Yes No
1
1. Remove the rear cover from the
printer.
2. Disconnect P401 and P402 from the
Engine Control Board.
3. Carefully reinsert the plugs into their
joint socket and FIRMLY seat them.
4. Did this fix the problem?
Complete. Replace the laser
unit.
(You must
perform the
RegiCon
Adjustment after
replacing the
laser unit.)
If the problem
persists, replace
the engine control
board.
