Service Parts Lists 9-49
Hardware Kits
Recommended Service Tools
The following service are recommended as a start for servicing the printer. As
additional tools are needed visit the following URL for help: http://
cpid.office.xerox.com/hardwaretools.html.
Parts Part number Qty Name and description (vendor description)
116-1912-00 Sensor Kit
116-1210-00 Sensor Flag Kit
116-1211-00 Roller Kit
116-1820-00 Tray 1/MPT Roller Kit
116-1300-00 Hardware Kit
065-0630-00 1 Complete Repackaging kit
065-0629-00 1 Internal repackaging kit
Part Number Description
003-0293-00 Driver, Magnetic 0.25” drive (no bits), 8” shank
003-0335-00 Tip, #1 Philips Bit, 0.25” drive
003-0336-00 Tip, #2 Philips Bit, 0.25” drive
640600 Mag 27020 Tip, 2.5 mm Hex Bit, 0.25” drive
600T02123 Hex Nutdriver, 5.5 mm (magnetic)
