Xerox 7750DXF - Phaser Color Laser Printer User Manual

3-10 Phaser 7750 Printer Service Manual
Error Messages and Codes Index Table
Code Error Message Chain-Link Page
10 Laser Unit Failure 06-380
06-381
06-382
06-383
06-385
pg. 3-12
11 Laser Unit Polygon Motor Failure 06-372 pg. 3-12
12 Yellow ATC Sensor Failure 09-380 pg. 3-13
13 Magenta ATC Sensor Failure 09-381 pg. 3-13
14 Cyan ATC Sensor Failure 09-382 pg. 3-13
15 Black ATC Sensor Failure 09-383 pg. 3-15
20 Transfer Roller Contact Failure 09-342 pg. 3-17
21 Transfer Roller Retract Failure 09-343 pg. 3-17
1st BTR Contact Failure 09-348 pg. 3-18
1st BTR Retract Failure 09-349 pg. 3-18
30 Accumulator Belt Home Position Took Too Long 04-346 pg. 3-19
31 Accumulator Belt Home Position Failure 04-347 pg. 3-19
32 Accumulator Belt Edge Sensor Failure 04-348 pg. 3-22
33 Unexpected Accumulator Belt Home Sensor Signal 09-350 pg. 3-24
34 Accumulator Belt Drive Logic Failure 09-351 pg. 3-22
35 Fuser Main Lamp Failure 10-348 pg. 3-25
41 Install or Reseat Fuser 10-349 pg. 3-26
42 Fuser STS (front) Warm Time Failure 10-352 pg. 3-27
43 Fuser SSR1 On Time Failure 10-353 pg. 3-27
44 Fuser Sub Lamp Failure 10-350 pg. 3-29
45 Fuser STS (rear) Failure 10-351 pg. 3-30
46 Fuser STS (rear) Warm Time Failure 10-354 pg. 3-31
47 Fuser SSR2 On Time Failure 10-356 pg. 3-31
48 Fan Failure 10-398 pg. 3-33
60 Imaging Unit Motor Failure, Code 60 04-361 pg. 3-35
70
71
72
73
Imaging Unit 1...
2
3
4... Communication Failure
09-360
09-361
09-362
09-363
pg. 3-36
