2-22 Phaser 7750 Printer Service Manual
Sensors
Looking at the imaging path illustration below, note that there are two kinds of
sensors that play an important role in the control of image quality for the printer.
Network
cable
Engine Board
I/P Board
Internal
Test
Patterns
Imaging Unit
Developer Housing &
ATC Sensors
ROS
Charge
Rolls
Toner
Cartridge
(4)
Output
ADC
Sensor
Fuser
2
nd
Transfer
Roller
1
st
Transfer
Roller
7750-452
7750-460
Transfer Roller Sensor
Tray 1 Take Away Sensor
Paper On Belt Sensor
Transparency Sensor
Registration Sensor - on left door optic
MPT No Paper Sensor
Tray 1 No Paper Sensor/Level Sensor
MPT Paper Size Sensor
