Xerox 7750DXF - Phaser Color Laser Printer - Page 59

Theory of Operation 2-23
7750-461
Accumulator Belt
Edge Sensor
Accumulator Belt
Home Sensor
Duplex
Wait Sensor
Automatic Toner
Concentration Sensor
K, C, M, Y
Environment
Sensor
Automatic Density
Control Sensor
Mark On
Belt Sensor
Waste Cartridge
Full Sensor
Tray 1 Paper
Size Sensor
