Xerox 7750DXF - Phaser Color Laser Printer User Manual

11-47
10
116-1285-00 Top Tray Full Sensor
11
116-1247-00 Exit Sensor
12
116-1286-00 Gate In Solenoid Assembly
13
Gate in Solenoid
14
Spring {p/o item 12}
15
Link
16
Cover
17
Ground Wire
18
Wire Harness
19
Wire Harness
20
Bearing
21
116-1281-00 Gear (37T)
22
116-1282-00 Gear (30T)
23
116-1283-00 Gear (26T)
24
116-1234-00 Interlock Sensor
25
Bracket
26
116-1267-00 Paper Guide
27
Roll
28
Bracket
29
Frame
30
Bracket
31
Screw
Horizontal Transport Assembly: 2 of 2 PL 17.4
No. Part Number Qty Description
