Service Parts Lists 9-23
Lift Unit PL 5.1
No Part number Qty Part Description and (part name)
1
116-1198-00 LH Frame Lift Assembly (FRAME ASSY-LIFT LH)
2
116-1199-00 RH Frame Lift Assembly (FRAME ASSY-LIFT RH)
3
116-1772-00 Bearing
4
116-1773-00 Washer
5
Plate N/S
6
116-1202-00 Lift Arm Latch Assembly (LATCH ASSY-AST)
7
116-1200-00 LH Handle Hinge (HINGE-HANDLE LH)
8
116-1201-00 RH Handle Hinge (HINGE HANDLE RH)
9
116-1203-00 Pivot Pin (SHAFT MAIN)
10
116-1204-00 Main Lift Handle Assembly (LEVER ASSY-MAIN)
