10-7
P612 Map 17 3 Developer Motor, Tray 2 Size Switch
J613 Map 3 10 Inverter Transport Assembly
P613 Map 17 5 Developer Motor, Tray 2 Size Switch
614 Map 1 18 Xerographic
617 Map 19 6 Left Lower Assembly, Tray 2 Feeder
619 Map 1 1 Xerographic
620 Map 5 6 Registration Transport Assembly
622 Map 1 22 Xerographic
623 Map 19 5 Left Lower Assembly, Tray 2 Feeder
624 Map 1 21 Xerographic
P626 Map 3 13 Inverter Transport Assembly
J626 Map 4 2 Duplex Transport Assembly
631 Map 1 23 Xerographic
J633 Map 3 3 Inverter Transport Assembly
P633 Map 3 7 Inverter Transport Assembly
639 Map 16 5 I/F PWB, MAIN Motor, LVPS T2
J640 Map 3 11 Inverter Transport Assembly
P640 Map 17 6 Developer Motor, Tray 2 Size Switch
641 Map 16 6 I/F PWB, MAIN Motor, LVPS T2
646 Map 17 8 Developer Motor, Tray 2 Size Switch
668 Map 12 15 HVPS T1, T3, +24V LVPS
669 Map 12 16 HVPS T1, T3, +24V LVPS
670 Map 20 9 TT Module (Tray 3,4 feeder)
672 Map 20 7 TT Module (Tray 3,4 feeder)
674 Map 23 9 TT Module (rear)
J800 Map 31 8 Finisher (rear) (1 0f 2)
P800 Map 16 21 I/F PWB, MAIN Motor, LVPS T2
801 Map 12 5 HVPS T1, T3, +24V LVPS
814 Map 20 5 TT Module (Tray 3,4 feeder)
815 Map 20 4 TT Module (Tray 3,4 feeder)
816 Map 22 5 TT Module (Tray 3,4,5, Paper Size Switch)
818 Map 20 5 TT Module (Tray 3,4 feeder)
Plug/
Jack No. Map Number Item No.
Title
To Next Page
