10-9
FS90 Map 18 18 AC Drive PWB, Noise Filter PWB, Delay PWB
FS134 Map 1 13 Xerographic
FS135 Map 1 14 Xerographic
FS180 Map 9 19 Toner Dispense Motor (Y,M,C,K), Main Switch
FS181 Map 9 1 Toner Dispense Motor (Y,M,C,K), Main Switch
FS182 Map 9 2 Toner Dispense Motor (Y,M,C,K), Main Switch
FS183 Map 9 3 Toner Dispense Motor (Y,M,C,K), Main Switch
FS184 Map 9 4 Toner Dispense Motor (Y,M,C,K), Main Switch
FS185 Map 9 5 Toner Dispense Motor (Y,M,C,K), Main Switch
FS186 Map 9 6 Toner Dispense Motor (Y,M,C,K), Main Switch
FS187 Map 9 7 Toner Dispense Motor (Y,M,C,K), Main Switch
FS812 Map 20 1 TT Module (Tray 3,4 feeder)
FS813 Map 20 2 TT Module (Tray 3,4 feeder)
Plug/
Jack No. Map Number Item No.
Title
