Xerox 7750DXF - Phaser Color Laser Printer User Manual

10-77
Drum Cleaning (Y, M as an Example)
9.26 DRUM CLEANING (Y,M)
MCU PWB PL13.1
DC COM
+24VDC
+24VDC
B2 B1
MCU PWB PL13.1
DC COM
+24VDC
B4 B3
J403
DC330 [009-045]
ERASE LAMP (Y)
ON (L) +24VDC
J223
YEL YEL
DOUBLE
PLUG
P223
1
1
2
2
ERASE LAMP (Y) PL4.2
+24VDC
J403
DC330 [009-045]
ERASE LAMP (M)
ON (L) +24VDC
J224
YEL YEL
DOUBLE
PLUG
P224
1
1
2
2
ERASE LAMP (M) PL4.2
9.5
9.20
CLEANER (Y)
DRIVE
CONTAMINATED
DRUM (Y)
9.6
9.21
CLEANER (M)
DRIVE
CONTAMINATED
DRUM (M)
9.5
9.29
CLEANED
DRUM (Y)
WASTE
TONER (Y)
9.6
9.29
CLEANED
DRUM (M)
WASTE
TONER (M)
7750-318
